Software for USB-DMX512 module
and DMX PIPE
Music Visualization
The program is designed for controlling
lights and other electronics by DMX512.
Visualization is based on data acquired from
music in real time. The system is focused on
creating such visualization that corresponds
with music produced with no need of
human intervention. SOH production. Demo
download. Additional
descriptions.
DMX512 Light Control
Simple program using full 512 DMX channels.
It functions as a blend between two scenes with
the automatic blending of scenes function. SOH
production. You can download it here:
Download. Version for Windows CE, Smartphone
or ARM4 processors:
Light Control CE
DMX512 PC Control
Universal program allowing for PC control
directly through the DMX512 protocol. A
simulation of keyboard is being used, whereby a
keyboard sequence and program can be assigned to
any channel for which it is designed. For the
processing of entry to the computer DMX PIPE (or
USB-DMX512 module) can be used, which functions
here as a receiver. The computer thereby becomes
a device controlled by DMX512 as well as other
light technology. SOH production. You can
download it here:
Download
FreeStyler 512
It is a very good program, which contains
complete libraries for lights (e.g. for Eurolite
TS-150, PR Pilot150). This program runs also
under Windows 98. For the correct functioning,
it is necessary to set compatible interface
“Enttec open DMX” in item “Setup”/”FreeStyler
Setup”. Instructions are part of the
installation. You can download it here:
Download
MasterPeace
Simulation of a real lighting Masterpiece
desk. Instructions to this desk are in
the “Instructions.pdf” file. This program does
not need installation. Communication with the DMX
PIPE (or USB-DMX512 module) interface starts
automatically after it is opened. You can
download it here:
Download
DMX Theatre
This program is very simple to use. It is
basically only a blend between two scenes. For
activation of the output on the DMX 512 line, it
is necessary to click on “Connect” first and
then on “Send” in the “Settings” menu. You can
download it here:
Download
DMXDesk – DMX Live Desk V10
It is an advanced program with graphic
interface of standard Windows. It is necessary
to set “Open USB DMX Adapter” as an output
interface. You can download it here:
Download
Abuelites
Graphically friendly program with variable
setting possibilities. Integrated audio player,
possibility to run two chase, control by MIDI
and others. Communication with connected DMX
PIPE interface runs automatically after it is
opened and it is not necessary to set up. You
can download it here:
Download
MaqicQ
Functional demo of the professional
program. The program can be switched from the
standard appearance for mouse control to the
touchpad control. It enables cooperation with
external desks. It is in modification for
Windows as well as MacOS and Linux operational
systems. For output interface setup it is
necessary to press “Setup” button, then “View
DMX I/O”. In the table set “Out Type” on “Open
USB” and “Status” on “Enabled”. You can download
it here:
Download
Sound Graffiti Dimmer
Demo of a simple program for the control of
darkening directly by audio signal. The demo is
functional for a 5-10 minute period and then
requires registration. It is necessary to set up
library “sg_EnttecUsbDmx.dll” as output
interface. You can download it here:
Download
P-Polites
Simulation of a simple lighting desk.
Communication with connected DMX PIPE interface
runs automatically after it is opened and it is
not necessary to set up. You can download it
here:
Download
Lightfactory
Time limited demo of PC
based lighting control system. Offering a no
compromise approach of traditional dimmer
control and fully featured moving light support.
LightFactory was designed with the idea that
every lighting engineer, operator or designer
could own their own control desk. One desk they
are completely familiar with, one desk that
works for every situation and one desk they can
rely on every time. The USB interface must be
set in menu "File" >> "System Properties" >>
"System" >> "DMX Out Hardware" to "Open USB-DMX".
You can download it here:
Download
SchwartzPeter
French
freeware, 120 channel theater console.
You can download it here:
Download
DMX Control
Multimedia program with graphical interface
of standard Windows. It allows for control by
joystick, keyboard, MIDI or simple audio
analyser. It contains for example light path
editor, 2D graphic visualization of planned out
scene, and audio player with the option of
manual synchronization of music scene. You can
download it here:
Download
MADRIX
It is a user-friendly,
reliable, and feature-rich Windows® software.
MADRIX supports a lot of well-known industry
standards, such as DMX512, Art-Net II, the
Philips ColorKinetics and Insta/Robe protocols,
and DVI. The application is both an effect
generator and media server with outstanding
capabilities to display unique effects.
You can download it here:
Download
QLC
QLC is a lighting controller
for Linux. Started as a university project by
Heikki Junnila, it has now evolved with an
active development community. In 2009 it was
released for Mac Os and Windows also.
You can download it here:
Download
DLP/LCD
Effects Projector
Effects projection for all DLP
or LCD projectors. Only the fog machine must be
used.
You can download it here:
Download
Other supported programs:
STL-DMX
DMX 4 Linux
Lights UP X
PureDada
Schwartzpeter
Manolator
StageConsole
Hip's Rsource page
Office Wing 1.0
Capture Visualiser
Pure Data Plugin
Illumination 110
Prozic
Madrix
SLight
MIDI to DMX
PC_DIMMER
Support:
SDK - Software development kit for module
USB-DMX512 and DMX PIPE for your own application
in C++:
DMX PIPE SDK
Test - DMX512
USITT compatible test.
Frequently Asked Questions - FAQ
USB-DMX512 manuals -
English,
Czech,
German
DMX PIPE Manuals -
English,
Czech,
German
